The 50mm (2″) Push/Pull Valve
Featuring PVC connections, available to suit pressure pipe. With #316 stainless steel spindle, nuts and bolts. Gates with EPDM seals. As with all Oz valves there is an unrestricted bore when open. Compatible with commonly used plumbing products.
Dimensions
Total Width: 131mm
Total Length: 105mm
Total Height(closed): 235mm
Total Height(open): 310mm
Bore Diameter: 50mm
Recommended for use at 50PSI
The 80mm (3″) Push/Pull Valve
Featuring PVC connections, available to suit pressure pipe. With #316 stainless steel spindle, nuts and bolts. Gates with EPDM seals.
As with all OZ Valves there is an unrestricted bore when open. Compatible with commonly used plumbing products.
Dimensions
Total Width: 165mm
Total Length: 127mm
Total Height (closed): 300mm
Total Height (open): 400mm
Bore Diameter: 80mm
Recommended for use at 50PSI
The 90mm (4″) Push/Pull Valve
Featuring PVC connections, available to suit pressure pipe. With #316 stainless steel spindle, nuts and bolts. Gates with EPDM seals.
As with all OZ Valves there is an unrestricted bore when open. Compatible with commonly used plumbing products.
Dimensions
Total Width: 165mm
Total Length: 127mm
Total Height (closed): 300mm
Total Height (open): 400mm
Bore Diameter: 90mm
Recommended for use at 50PSI
The 100mm (4″) Push/Pull Valve
Featuring PVC connections, available to suit both DWV and pressure pipe.
With #316 stainless steel spindle, nuts and bolts. Gates available with EPDM seals.
As with all Oz valves there is an unrestricted bore when open. Compatible with commonly used plumbing products.
Dimensions
Total Width: 195mm
Total Length: 155mm
Total Height(closed): 345mm
Total Height(open): 470mm
Bore Diameter: 110mm
Recommended for use at 50PSI
The 100mm (4″) Push/Pull Valve P/P
Featuring PVC connections, available to suit both DWV and pressure pipe.
With #316 stainless steel spindle, nuts and bolts. Gates available with EPDM seals.
As with all Oz valves there is an unrestricted bore when open. Compatible with commonly used plumbing products.
Dimensions
Total Width: 195mm
Total Length: 155mm
Total Height(closed): 345mm
Total Height(open): 470mm
Bore Diameter: 114mm
Recommended for use at 50PSI
The 150mm (4″) Push/Pull Valve
Featuring a polyurethane body with PVC connections and #316 stainless steel components (gate, spindle, nuts and bolts) the 150mm valve is the rust proof, UV stabilised flagship of the Oz Valves range. By it’s nature spares are not available for this valve.
To suit pressure, DWV or storm water pipe.
Dimensions
Total Width: 250mm
Total Length: 200mm – 290mm
Total Height(closed): 400mm
Total Height(open): 520mm
Bore Diameter: 150mm
Recommended for use at 20PSI
Spare Parts
Should you ever need to acquire part of one of our valves due to damage to an existing valve, excessive wear or even as part of your own valve project, we have all Oz Valves components available to you. Please contact us for further details or to discuss your requirements.
Parts available include:
- Push/Pull Knobs.
- Gland Nuts.
- Gland Seal.
- Spindles.
- Gaskets/”O” Rings.
- Valve top (100mm, 80mm, 50mm.
- Valve Body (100mm, 80mm, 50mm.
- Gates EPDM seal.
